Big Creek, Florence Lake Dam

Description
Big Creek, Florence Lake Dam - One of the four 1.5" diameter drains through the arch approximately 1' above the lower horizontal key before covering with facing steel. Pipes were sulfured and grouted in. 1.5" iron stop cocks were placed on the downstream ends of the pipes.
Type
Visual Materials(Opens in new tab)
Date
5/20/1942
Call number
photCL SCE 02 - 24703
Find out more
View in the Huntington Digital Library(Opens in new tab)
View in the Library catalog(Opens in new tab)
